Oil Water Separator
STANDARD, EPS-M, EPS-D, EPS-S
- 1. Compositions : Pre treatment tank+ Oil water separating tank + Filtering tank + Re-oil separating tank
- 2. Performance : To separate oil at 990000 PPM being in mixtures of oil and water into no more than 5 PPM
- 3. Applications : Discharging
- 4. Where to Use : The place needs discharge after oil water separation / Water wasted from freezing of compression plant, from casting, and from subway / Oil pipe, oil company, press plant, power generation station, petrochemical plants, car washing plant
- 5. Features : STANDARD products of EPS Oil water separator; it is easy to install and to treat a great amount of oil.
Specification
※ You can check the contents by scrolling left/right.
| MODEL No. |
CAPACITY (m³/hr) |
DIMENSION (INCLUDING FILTERING PART) (L X W X H) (M) |
SIZE OF PIPE (A) | SHIPPING WEIGHT (T) |
OPERATING WEIGHT (T) |
||||
|---|---|---|---|---|---|---|---|---|---|
| MAIN BODY | OIL SEPARATOR IN REPEAT | IN | OUT | OIL | DRAIN | ||||
| EPS-0.5 | 0.5 | 2.0X0.32X0.9 | 0.5X0.2X0.5 | 20 | 32 | 32 | 20 | 0.9 | 2.0 |
| EPS-1 | 1 | 2.44X0.32X0.9 | 0.5X0.2X0.5 | 20 | 32 | 32 | 20 | 1.2 | 3.0 |
| EPS-2 | 2 | 2.44X0.62X0.9 | 0.6X0.25X0.6 | 25 | 40 | 32 | 25 | 1.5 | 4.0 |
| EPS-3 | 3 | 2.44X0.62X1.22 | 0.6X0.25X0.6 | 25 | 40 | 32 | 25 | 1.8 | 5.0 |
| EPS-5 | 5 | 2.90X0.62X1.22 | 0.6X0.3X0.6 | 25 | 50 | 40 | 25 | 2.0 | 6.0 |
| EPS-8 | 8 | 3.00X0.92X1.22 | 0.7X0.35X0.7 | 32 | 65 | 50 | 32 | 2.2 | 9.0 |
| EPS-10 | 10 | 3.40X1.22X1.22 | 0.8X0.35X0.7 | 40 | 65 | 50 | 32 | 2.6 | 12.0 |
| EPS-15 | 15 | 3.60X1.22X1.53 | 0.8X0.35X0.8 | 50 | 80 | 65 | 32 | 3.0 | 15.0 |
| EPS-20 | 20 | 4.30X1.52X1.53 | 0.8X0.35X0.8 | 50 | 80 | 65 | 40 | 3.5 | 19.0 |
| EPS-25 | 25 | 4.90X1.52X1.53 | 0.9X0.35X0.9 | 65 | 100 | 80 | 40 | 3.9 | 20.0 |
| EPS-30 | 30 | 4.90X1.82X1.53 | 0.9X0.4X0.9 | 65 | 100 | 80 | 50 | 4.5 | 21.3 |
| EPS-40 | 40 | 5.30X1.82X1.53 | 0.9X0.4X0.9 | 65 | 125 | 80 | 50 | 5.6 | 28 |
| EPS-50 | 50 | 5.80X1.82X1.84 | 0.9X0.4X0.9 | 80 | 150 | 100 | 65 | 6.5 | 32 |
| EPS-70 | 70 | 6.00X1.82X2.14 | 1.0X0.4X1.0 | 80 | 150 | 100 | 65 | 8.8 | 50 |
| EPS-100 | 100 | 6.50X2.13X2.45 | 1.0X0.5X1.0 | 100 | 200 | 150 | 80 | 13.5 | 76 |
| EPS-150 | 150 | 8.20X2.13X2.45 | 1.2X0.5X1.2 | 100 | 200 | 150 | 80 | 21.5 | 92 |
| EPS-200 | 200 | 8.90X2.44X3.05 | 1.5X0.6X1.2 | 125 | 250 | 200 | 100 | 35.0 | 134 |
* Notice) Size is subjective according to oil property and oil contains.
